Item code 68244

Egalsoft FR 6 mm: 22 x 1.37 m (30.14 m²)

Egalsoft FR® is a unique fire-retardant anti-slip underlay that ensures a durable and easy installation, suitable for both residential and commercial use.
Egalsoft FR® is a unique fire-retardant anti-slip underlay that provides a durable and easy installation. The underlay is an impregnated nonwoven material with an anti-slip treated layer, ideal for both residential and commercial applications.
Floor type Carpet
Product weight 900 g/m²
Product dimensions (Length) 22 m
Product dimensions Width (Unit) m
Product dimensions in m2 30.14 m²
Base unit Roll
Thickness 6 mm
Density 150 kg/m³
Material Top layer: PP SpunbondMiddle layer: impregnated nonwovenBottom layer: anti-slip treated layer
Brand Egalsoft
Thermal resistance - R-value 0.22 m² K/W
TOG rating 2.2 TOG
VOC label A+
Dimensional stability tensile strength / Long / MD - unit kN/m
Dimensional stability tensile strength / Cross / CD > 20.0
Dimensional stability tensile strength / Cross / CS - unit kN/m
Dimensional stability elongation / stretch / Long / MD - unit %
Dimensional stability elongation / stretch / Across / CD > 20
Dimensional stability elongation / stretch / Across / CS - unit %
Domestic use Yes
Project use Yes
Laying method Stretching / single-sided bonding / double-sided bonding
DIBT certificate Z-158.10-98
Product dimensions (Unit)
Type of base floor Wooden floor / Fixed sand cement floor / Floating screed
Wheelchair load (Test method: EN 985) Suitable
Sound-reducing - ΔLw 27 dB ΔLw
Flame-retardant Bfl-S1
Flame-retardant - Test method EN 13501-1
Dimensional stability tensile strength / Long / MD > 7.0
Dimensional stability elongation / stretch / Long / MD > 50
Dimensional stability tensile strength / Long / MD - Test method DIN EN 10319
Dimensional stability tensile strength / Cross / CD - Test method DIN EN 10319
Dimensional stability elongation / stretch / Long / MD - Test method DIN EN 10319
Laying direction Perpendicular to the carpet installation direction. Avoid aligning the seams of the underlay and carpet.
Suitable for stair installation Yes
Green Choice Yes
